SMARTPAR 1920P

The SMARTPAR 1920P is an IP65 rated high power indoor LED flat par light using 19*20W 6-IN-1 RGBWA+UV LEDs which is designed with 3 individual rings. It’s available for 2500K-6500K color temperature adjustment.

It features excellent color mixing, quiet running and flicker free control. The fixture is built in with internal dynamic effects with variable speed. The PAR also features optimum optic design integrated with extremely effective aluminum heat sink system.

The SMARTPAR 1920P is designed for applications as concerts, TV studios, conference halls, bars, pubs, DJ entertainment, architectural lighting projects, gardens, theme parks, etc.

Technical specifications

Light Source

Source:19*20W 6-IN-1 LEDs (RGBWA+UV)

3 Individual control rings

Flicker free operation for broadcast TV and FILM

Life Span: 50000H

The life span may vary depending on several following factors but not limited to:

Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming)

Optics

High efficiency optic system

25°Beam angle (other angles optional)

35°Field angle

High output

Color System

RGBWA+UV

Smooth and pure color mixing capability

CTO, 2500K-6500K color temperature adjustment

Built-in Programs

Different built-in dynamic effects with variable speed

Different preset colors

Strobe Effect

0-25Hz LED shutter/strobe effect with variable speed

Dimming System

0-100% Smooth linear LED dimming

Control System

4/7/9/11/18 DMX channels DMX512, master-slave, or auto operation
DMX recorder and edit function integrated
RDM available
(Remote Device Management)
Art-NET (Optional)
Wireless receiver system built-in (Optional)
Shielded input signal protection for stable signal without interference
Waterproof RJ45 etherCON IN
(Optional with Art-Net)
Waterproof SEETRONIC’s 3-Pin or 5-pin XLR DMX connectors IN/OUT

Display System

1.44” TFT LCD display

4 Touch control buttons

180°Reversible for LCD display

Display auto OFF

DMX signal and error monitoring indicators

Cooling System

Advanced low noise self-adjusting fan cooling system integrated aluminum

Constant temperature readout and management function

Over temperature protection management

Power Supply

Electronic supply with active PFC
AC100-240V 50/60Hz
Waterproof SEETRONIC’s TRUE1 powerCON
